Model Specific Features

• Available for mechanical remote or tiller control
• Only 353 pounds
• Available in 20” or 25” shafts
• Powerful 35-amp alternator
• Optional Variable Trolling RPM via the Command Link® tachometer

Specifications

• Engine Type: Inline 4
• Displacement: 1.8L
• Bore x Stroke: 81 x 88.9mm (3.19 x 3.5 in)
• Prop Shaft Horsepower: 90hp @ 5500 rpm
• Full Throttle RPM Range: 5000 ~ 6000
• Alternator Output at W.O.T.: 35 Amp
• Compression Ratio: 10.0:1
• Fuel Induction System: EFI
• Weight*: 160kg (353 lbs)
• Recommended Fuel: Octane 87
• Recommended Engine Oil: Yamalube® 4M (See owner’s manual)
• Recommended Fuel Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
• C.A.R.B. Rating: 3-Star
• Exhaust: Through Propeller
• Intake: 16
• Ignition: TCI Microcomputer
• Spark Plug: LFR6A-11
• Alternator Output: 35 Amp
• Starting System: Electric
• Lubrication: Wet Sump
• Engine Oil Capacity: 3.2/3.0L
• Recommended Cooling: Thermostatic Control
• Ethanol Blend Limit: 10% Maximum
• Gear Ratio: 2.15:1
• Gear Shift: Forward, Neutral, Reverse
• Shaft Length: 20″
• Degree of Tilt: 70
• Degree of Trim: -4° through +66°
• Dry Weight: 160kg (353 lbs)
• Mounting Centers: 26″
• Steering Angle (maximum): 35° from center, either direction
